Large Aperture Rotary Tables ndi zida zoyika molunjika bwino zomwe zili ndi pakati pa-bowo, zomwe zimagwiritsidwa ntchito makamaka m'mafakitale omwe amafunikira kuti azidutsa-zingwe zazikuluzikulu zogwirira ntchito, zingwe, mapaipi, kapena njira zowonera. Cholinga chake chachikulu ndikupereka pobowo wapakati (kawirikawiri Woposa kapena wofanana ndi 100mm) kupitirira kutali ndi malo ozungulira opanda kanthu pomwe amaonetsetsa kuti{4}}ayike mozungulira, motero kuthetsa zosowa zozungulira, kuyang'ana, kusonkhanitsa, ndi zina zazikulu kapena zazitali zogwirira ntchito.

Large Aperture Rotary Tables ndi mapulaneti ozungulira opangidwa mwapadera okhala ndi mbali yaikulu yapakati kupyola-bowo (ngakhale mpaka mita imodzi kapena kuposerapo), oyenera kuyika makina akuluakulu-akuluakulu ogwirira ntchito, mawaya amkati, kapena ma transmission oonera. Mtundu uwu wa tebulo lozungulira umakhala ndi gawo lofunikira pakupanga molondola, kuyang'ana maso, zakuthambo, ndi zida zofufuzira zasayansi.

Mapangidwe a Large Aperture Rotary Tables amayenera kulinganiza kutsutsana pakati pa "bowo lalikulu", "kulondola kwambiri", ndi "katundu wapamwamba", chifukwa chake ali ndi mikhalidwe iyi:

Chapakati chachikulu kupyola-bowo	1) Kabowo osiyanasiyana: kawirikawiri 100mm ~ 1000mm, ena makonda zitsanzo akhoza kukhala lalikulu, lalikulu kuposa wamba dzenje pozungulira nsanja (zobowo wamba zambiri 20mm ~ 80mm). 2).Cholinga chodutsa-bowo: Lolani zogwirira ntchito zazitali (monga ma shaft ndi ndodo), njira zowunikira ma laser, ma bundle a chingwe, mapaipi a mpweya, mapaipi ozizirira, ndi zina zambiri, kuti zidutse, kupewa kusokonezedwa ndi makina.
Mkulu mwatsatanetsatane malo ntchito	1).Kubwerezabwereza kwa malo: nthawi zambiri mpaka ± 0.01mm 0.005mm, kulondola koyika ma angle Ochepera kapena ofanana ndi masekondi a 10 arc (zina zapamwamba-zitsanzo zomaliza Zochepera kapena zofanana ndi masekondi 5 arc). 2) .Low Backlash: Pang'ono kapena yofanana ndi 1 arc miniti (0.0167 digiri), kuonetsetsa kuti palibe kupanikizana kapena kuyikika kosiyana panthawi yozungulira.
Mkulu katundu ndi kuuma	1) .Axial katundu: akhoza kupirira zolemera kuyambira mazana kilogalamu matani angapo (monga 500kg ~ 5000kg), oyenera workpieces lalikulu. 2) .Radial load: Zapangidwira cantilever kapena eccentric workpieces, zimakhala ndi mphamvu zotsutsana ndi kugwedezeka kwa mphindi (monga Kuposa kapena kufanana ndi 1000N • m). 3).Kusasunthika: Kupangidwa ndi-chitsulo chowulungika champhamvu kwambiri kapena zitsulo zotayidwa za aluminiyamu, zolumikizidwa ndi ma berelo oyenda bwino kuti achepetse kupindika ndi kugwedezeka panthawi yozungulira.
Kuyendetsa ndi Kuwongolera	1).Drive mode: Nthawi zambiri imagwiritsa ntchito ma servo motors ndi zochepetsera bwino mapulaneti, zomwe zimathandiza -kuzungulira kosalala bwino komanso-kuthamanga kwambiri{3}}kuthamanga kwambiri (nthawi zambiri liwiro limakhala 0.1rpm~300rpm). 2). Dongosolo la ndemanga: zokhala ndi-zosindikiza zolondola kwambiri za grating kapena encoder yamtengo wapatali, zenizeni-kuyang'anira nthawi yozungulira, kupeza njira yotseka{4}}loop control.

Kusiyanitsa ndi nsanja wamba yozungulira yopanda phokoso

Mawonekedwe	Wamba dzenje pozungulira nsanja	Pulatifomu yayikulu yozungulira
Pobowo wapakati	20 mpaka 80 mm	Kuposa kapena kofanana ndi 100mm (customizable to 1000mm kapena kuposa)
Katundu kuchuluka	Katundu wa Axial nthawi zambiri amakhala wosakwana 50kg	Axial katundu akhoza kufika 500kg ~ 5000kg
Ntchito workpiece kukula	Chogwirira ntchito chaching'ono, chachifupi	Chachikulu, chachitali kapena kudzera mwa mtundu wa workpiece
Zochitika za Ntchito	Electronic Assembly, Small Laser Marking, etc.	Heavy Duty Processing, Large Equipment Inspection, etc
Kuvuta kwamapangidwe	Voliyumu yosavuta, yocheperako	Mapangidwe okhuthala, ofunikira kukhazikika kolimba

Large Aperture Rotary Tables ndi oyenera kugwira ntchito zomwe zimafuna mabowo aakulu, kulemedwa kwakukulu-kuchuluka kwamphamvu, ndi kuzungulira kolondola, ndipo ndi kosasinthika m'mbali za optics, mlengalenga, ndi makina olemera{1}}. Posankha, chidwi chapadera chiyenera kuperekedwa pa kabowo, kuuma, ndi kulondola, ndipo zofunikira zogwiritsira ntchito ziyenera kusiyanitsidwa ndi Hollow Rotary Tables.

Pano Patsamba lino, tikuyambitsa Matebulo Akuluakulu Akuluakulu Akuluakulu, muwona pepala, zithunzi zopanga, ma vedio oyesa motere:

Komanso Mwalandiridwa kuti muwonere mapulojekiti ena kapena kuchezera makanema athu ndi YouTube: https://www.youtube.com/@tallmanrobotics

Mndandanda	Large Hollow Rotary Tables
Zitsanzo	Mtengo wa TMN60		Mtengo wa TMN85		Mtengo wa TMN130		Mtengo wa TMN200		Mtengo wa TMN280		Mtengo wa TMN465
Zithunzi
Mtundu Wokhala	Mtanda wodzigudubuza		Mtanda wodzigudubuza		Mtanda wodzigudubuza		Mtanda wodzigudubuza		Mtanda wodzigudubuza		Mtanda wodzigudubuza
Kufananiza Motor	50W / 100W Servo 42/57 Stepper Motor		200W / 400W Servo 57/60/86 Stepper Motor		200W / 400W Servo 57/60/86 Stepper Motor		750W/1KW Servo mota 86/110 Stepper Motor		1KW-2KW Servo injini 110-130 Stepper Motor		2KW-5KW Servo motere
Khomo Loyera	28 mm		33 mm pa		62 mm pa		100 mm		150 mm		300
Kuchepetsa Chiŵerengero	5	10	5	10	10	18	10	18	10	18	10
Torque yovomerezeka	12 N.m	7.5 N.m	41 N.m	27 N.m	60 N.m	37 N.m	115 N.m	68 N.m	150 N.m	125 N.m	456 N.m
Nthawi yovomerezeka ya torque	24 N.m	15 N.m	82 N.m	54 N.m	120 N.m	74 N.m	230 N.m	136 N.m	300 N.m	250 N.m	767 N.m
Liwiro lovomerezeka la mbale	200 Intermittent ntchito (rpm)
Max kugubuduza torque	142 N		380 N		1200N		2600N		125 N.m		300 N.M
Max radial mphamvu	1930 N		4800 N		8400N		12500N		16500N		18600N
Max axial mphamvu	1930 N		4800 N		8400N		12500N		16500N		18600N
Kukhazikika kwa Torsion	2.5Nm/arcmin		5.9 Nm / arcmin		16 Nm/arcmin		28.6 Nm / arcmin		58Nm/arcmin		65Nm/arcmin
Malo Olondola	± 0.5 arc/mphindi		± 0.5 arc/mphindi		± 0.5 arc/mphindi		± 0.5 arc/mphindi		± 0.5 arc/mphindi		± 0.5 arc/mphindi
Bwerezani Maimidwe	Zochepera kapena zofanana ndi 10 arc/mphindi		Zochepera kapena zofanana ndi 10 arc/mphindi		Zochepera kapena zofanana ndi 10 arc/mphindi		Zochepera kapena zofanana ndi 10 arc/mphindi		Zochepera kapena zofanana ndi 10 arc/mphindi		Zochepera kapena zofanana ndi 10 arc/mphindi
Platform Runout	Zocheperapo kapena zofanana ndi 0.01mm		Zocheperapo kapena zofanana ndi 0.01mm		Zocheperapo kapena zofanana ndi 0.01mm		Zocheperapo kapena zofanana ndi 0.01mm		Zocheperapo kapena zofanana ndi 0.01mm		Zocheperapo kapena zofanana ndi 0.01mm
Kuthamanga kwa radial	Zocheperapo kapena zofanana ndi 0.01mm		Zocheperapo kapena zofanana ndi 0.01mm		Zocheperapo kapena zofanana ndi 0.01mm		Zocheperapo kapena zofanana ndi 0.01mm		Zocheperapo kapena zofanana ndi 0.01mm		Zocheperapo kapena zofanana ndi 0.01mm
Kukhazikika kwa nsanja	Zocheperapo kapena zofanana ndi 0.01mm		Zocheperapo kapena zofanana ndi 0.01mm		Zocheperapo kapena zofanana ndi 0.01mm		Zocheperapo kapena zofanana ndi 0.01mm		Zocheperapo kapena zofanana ndi 0.01mm		Zocheperapo kapena zofanana ndi 0.01mm
Parallelism ya Platform	Zocheperapo kapena zofanana ndi 0.01mm		Zocheperapo kapena zofanana ndi 0.01mm		Zocheperapo kapena zofanana ndi 0.01mm		Zocheperapo kapena zofanana ndi 0.01mm		Zocheperapo kapena zofanana ndi 0.01mm		Zocheperapo kapena zofanana ndi 0.01mm
Moyo (Maola)	>20,000		>20,000		>20,000		>20,000		>20,000		>20,000
Njira yothira mafuta	Mafuta a Synthetic Lubricant
Gulu la Chitetezo	IP50		IP50		IP50		IP50		IP50		IP50
Njira yoyika	Ngongole iliyonse		Ngongole iliyonse		Ngongole iliyonse		Ngongole iliyonse		Ngongole iliyonse		Ngongole iliyonse
Kutentha kwa ntchito	-25 digiri -90 digiri		-25 digiri -90 digiri		-25 digiri -90 digiri		-25 digiri -90 digiri		-25 digiri -90 digiri		-25 digiri -90 digiri
Kulemera (kg)	0.54		1.4		2.5		8.0		20		52

Mndandanda

Hollow Rotary Platforms ndiZida za PlanetaryWochepetsera

Zithunzi

product-150-150 product-118-102 product-119-99

Zitsanzo

Mtengo wa TMN60-F

Mtengo wa TMN85-F

Mtengo wa TMN130-F

Mtengo wa TMN200-F

Mtengo wa TMN280-F

Mtengo wa TMN456-F

Matchable Motor (W)

50W / 100W servo

42/57 otsika

200W / 400W servo

57/60/86 stepper

50W, 100W servo

42/57 otsika

200W / 400W servo

57/60/86 stepper

750/1000W servo

86/110 wopondaponda

1KW-2KW servo

110-130 masitepe

2KW-7.5KW servo motor

Pobowo (Dia mm)

28 mm

33 mm pa

62 mm pa

100 mm

150 mm

300

Mtundu woberekera (i)

Mtanda wodzigudubuza

Kuchepetsa (i)

15/20/25/35/40/50

15/20/25/35/50

45/60/70

30/40/50/70/100

Torque yovomerezeka (Nm)

115

150

200

Nthawi yovomerezeka Inertia(r/min)

120

230

300

Liwiro lololeka (Nm)

200

466

Nthawi yovomerezeka yogubuduza (N)

142

380

1200

2600

125

767

Max Radial Force (N)

1930

4800

8400

12500

16500

18600

Max Axial Force (Nm/arc-min)

1930

4800

8400

12500

16500

18600

Torsion Rigidity (Arc-min)

2.5

6.0

5.9

Kuyika molondola (Arc{0}}mphindikati)

±0.5

Positionability repeatability (Arc-sec)

Zochepera kapena zofanana ndi 15

Nkhope yozungulira nsanja imatha

Ochepera kapena ofanana ndi 0.01 (mm)

Pulatifomu yozungulira yozungulira yatha (mm)

Zocheperapo kapena zofanana ndi 0.01

Kuzungulira kwa nsanja (mm)

Zocheperapo kapena zofanana ndi 0.01

Kufanana kwa nsanja yozungulira (mm)

Zocheperapo kapena zofanana ndi 0.01

Moyo wothandizira (maola)

>20000

Kutentha kwa ntchito (digiri)

-25 digiri ~{1}} digiri

Njira yothira mafuta

Mafuta opangira mafuta

Gulu lachitetezo (IP)

IP50

Njira yoyika

Ngongole iliyonse

Kulemera (kgs)

0.91

2.43

1.69

3.86

12.67

300

Mndandanda	Mapulatifomu Ozungulira Ozungulira Okhala ndi Zochepetsera Kumanja (mtundu wa R ndi mtundu wa Z)
Zithunzi	Mtundu wa R				Z mtundu
Zitsanzo	Mtengo wa TMN60-R Mtengo wa TMN60-Z	Mtengo wa TMN85-R Mtengo wa TMN85-Z		Mtengo wa TMN85-R Mtengo wa TMN85-Z	Mtengo wa TMN130-R Mtengo wa TMN130-Z	Mtengo wa TMN200-R Mtengo wa TMN200-Z		Mtengo wa TMN280-Z		Mtengo wa TMN456-Z
Matchable Motor (W)	50W / 100W servo 42/57/60 stepper	200W / 400W servo 57/60/86 stepper		50W, 100W servo 42/57 otsika	200W / 400W servo 57/60/86 stepper	750/1000W servo 86/110 wopondaponda		1KW-2KW servo 110-130 masitepe		2KW-7.5KW servo motor
Pobowo (Dia mm)	28 mm	33 mm pa		33	62 mm pa	100 mm		150 mm	300
Mtundu woberekera (i)	Mtanda wodzigudubuza
Kuchepetsa (i)	10/15/20/25/30/50	10/15/20/25/50		30/45/70	20/30/50/90	20/30/50/90		30/40/50/70/100
Torque yovomerezeka (Nm)	12	41		20	60	115		150		200
Nthawi yovomerezeka Inertia(r/min)	24	82		40	120	230		300		300
Liwiro lololeka (Nm)	200	200		200	200	200		200
Nthawi yovomerezeka yogubuduza (N)	142	380		380	1200	2600		125
Max Radial Force (N)	1930	4800		4800	8400	12500		16500		18600
Max Axial Force (Nm/arc-min)	1930	4800		4800	8400	12500		16500		18600
Torsion Rigidity (Arc-min)	2.5	6.0		5.9	16	28		39		65
Kuyika molondola (Arc{0}}mphindikati)	±0.5	±0.5		±0.5	±0.5	±0.5		±0.5		±0.5
Positionability repeatability (Arc-sec)	Zochepera kapena zofanana ndi 15	Zochepera kapena zofanana ndi 15		Zochepera kapena zofanana ndi 15	Zochepera kapena zofanana ndi 15	Zochepera kapena zofanana ndi 15		Zochepera kapena zofanana ndi 15		Zochepera kapena zofanana ndi 15
Nkhope yozungulira nsanja imatha	Ochepera kapena ofanana ndi 0.01 (mm)	Ochepera kapena ofanana ndi 0.01 (mm)		Ochepera kapena ofanana ndi 0.01 (mm)	Ochepera kapena ofanana ndi 0.01 (mm)	Ochepera kapena ofanana ndi 0.01 (mm)		Ochepera kapena ofanana ndi 0.01 (mm)		Ochepera kapena ofanana ndi 0.01 (mm)
Pulatifomu yozungulira yozungulira yatha (mm)	Zocheperapo kapena zofanana ndi 0.01	Zocheperapo kapena zofanana ndi 0.01		Zocheperapo kapena zofanana ndi 0.01	Zocheperapo kapena zofanana ndi 0.01	Zocheperapo kapena zofanana ndi 0.01		Zocheperapo kapena zofanana ndi 0.01		Zocheperapo kapena zofanana ndi 0.01
Kuzungulira kwa nsanja (mm)	Zocheperapo kapena zofanana ndi 0.01	Zocheperapo kapena zofanana ndi 0.01		Zocheperapo kapena zofanana ndi 0.01	Zocheperapo kapena zofanana ndi 0.01	Zocheperapo kapena zofanana ndi 0.01		Zocheperapo kapena zofanana ndi 0.01		Zocheperapo kapena zofanana ndi 0.01
Kufanana kwa nsanja yozungulira (mm)	Zocheperapo kapena zofanana ndi 0.01	Zocheperapo kapena zofanana ndi 0.01		Zocheperapo kapena zofanana ndi 0.01	Zocheperapo kapena zofanana ndi 0.01	Zocheperapo kapena zofanana ndi 0.01		Zocheperapo kapena zofanana ndi 0.01		Zocheperapo kapena zofanana ndi 0.01
Moyo wothandizira (maola)	>20000	>20000	>20000		>20000	>20000		>20000		>20000
Kutentha kwa ntchito ( digiri )	-25 digiri ~{1}} digiri	-25 digiri ~{1}} digiri	-25 digiri ~{1}} digiri		-25 digiri ~{1}} digiri	-25 digiri ~{1}} digiri		-25 digiri ~{1}} digiri		-25 digiri ~{1}} digiri
Njira yothira mafuta	Mafuta opangira mafuta
Gulu lachitetezo (IP)	IP50
Njira yoyika	Ngongole iliyonse
Kulemera (kgs)	1.1	2.66		1.69	3.86		12.67	33		300

Zosankha
Dalaivala ndi Chingwe	Dalaivala ndi chingwe pazosankha, zoperekedwa ndi Tallman Robotic Limited (Usaullay, timakonza Delta, Inovance, Pulse, EtherCat, Profinet zilipo)
Mbale yozungulira nkhope	Kuperekedwa ngati kuli kofunikira.(Zojambula zimaperekedwa ndi makasitomala)
Zomverera	Zomverera za Ormon, mabulaketi, mbale za sensor, zomangira ndizosankha.
